haze meter for color, haze and transmittance measurement

1. these are new haze meter produced by chnspec tech.
猬団瑖猬?strong>click the pictures for more details猬団瑖猬?br />
cs-720 color and haze meter cs-700 haze meter

type	cs-720	cs-700
light source	haze/transmittance锛欳ie-a,cie-c,cie-d65 chromaticity value锛欰,c,d50,d55,d65,d75,f1~f10, f11,f12,cmf,u30,dlf,nbf,tl83,tl84	cie-a,cie-c,cie-d65
standards	astm d1003/d1044,iso13468/iso14782 cie no.15,iso 7724/1,astm e1164, din 5033 teil7,jis z8722 condition c standard	astm d1003/d1044; iso13468/iso14782;
parameters	color, haze and transmittance	haze and transmittance

2. haze meter introduction
haze is the light deviated from the incident light which is greater than 2.5 ° compared to the total transmitted light.

transmittance is the total incident light compared to the total transmitted light.
haze measurement

haze meter is designed for plastic, films, glass, lcd panel, touch screen other transparent and semi-transparent materials color, haze and transmittance measurement.
鈼?conform to astm and iso standard.
鈼?3 kinds of light sources a,c and d65 for measurement.
鈼?cs-720 is with powerful color measurement function, it provides all measurement indexes and light sources.
鈼?open measurement area, no limit on sample size. vertical measurement is also available.
鈼?5.0 inches tft display screen.
鈼?instrument is with haze and transmittance measurement software.

3. haze meter instrument structure

how to use the instrument?

鈼?0% calibration and 100% calibration
note: if we calibrate instrument under iso standard, the compensate port should be open (the cover should be taken off). if it is under astm standard, compensate port should be covered.
when 100% calibration is done, we will get incident light flux t1 and scattering light flux t3, and then save them to calculate haze and transmittance.

鈼?astm standard
when transmittance is measured, sample will be put on measurement aperture, blade will cover the light trap for measurement, and then we will get transmittance light flux t2.
when haze is measured, sample will be put on measurement aperture, blade will cover the light trap for measurement, we will get transmittance light flux t2. then blade will come to the compensate port, after measure, we will get instrument and sample scattering light flux t4.

鈼咺so standard
when transmittance is measured, sample will be put on compensate port, blade will cover the light trap, then measure, we will get incident light flux t1 to replace the 100% calibration value. and then put the sample on the measurement aperture, blade position will not change, after measure, we will get the transmittance light flux t2

when haze is measured, sample will be put on measurement aperture, blade will cover the light trap, after measurement, we will get transmittance light flux t2. then blade will come to the compensate port, after measure, we will get instrument and sample scattering light flux t4.

4.haze meter application examples

5.chnspec haze meter advantages

name	chnspec haze meter	other brand
price	better user experience and half price	expensivre
software custom made service	we can design haze meter software according to customer’s requirement	without
storage	20000 samples	5000 samples
light source	haze/transmittance锛欳ie-a銆丆ie-c銆丆ie-d65
geometry	0/d
spectral response	cie luminosity function y
measurement range	0-100%
repeatibility	≤0.1

if any inquiry for color haze and transmittance measurement, please contact us directly. email:ivyzhang@colorspec.cn and tel 86 18768499725.
