1. introduction
the non-contact on-line gloss measuring system provides products’ glossy data for production gloss quality control, to improve quality control level and save operating expenses. the system is easy to install and manage, can be found through real-time control and solve the problem of gloss without interrupting production.

2. instrument advantages
1).non-contact
100% online gloss measurement, non-contact, non-destructive gloss measurement

2).automatically online gloss measurement
100mm measurement distance allows instrument to move away from the moving products on production line to provide flexible online installation condition and reduce the possibility of damage to equipment and materials.

3).adjustable measurement height
the measurement height is adjustable to make it suitable for measuring materials with difference thickness.

4).can measure material with angles (irregular material)
angle is adjustable to ensure that the product measuring surface and optical path is 60 °, so it is also suitable to measure products with difference thickness.

2. technical data and price list

type	non-contact gloss measurement system
test angles	60 degree
measurement spot(mm)	25x55
measurement range	0-1000gu
stability	0.1gu
measurement mode	continuous test and single test
measurement repeatability	0-100gu锛?.3gu 100-1000gu锛?.3%gu
measurement time	less than 0.5s
instrument size(mm)	1500x700x1200 (length x width x height) we can also custom made the size according to the customer’s requirement
weight	about 60kgs
language	english
interface	usb
gloss qc software	including
working temperature	0-40鈩?/span>
humidity	less than 85%, no condensation
packing list	gloss sensor, instrument supports, calibration tile, power adaptor, gloss color qc software
