    bench-top spectrophotometer
    cs-801

      cs-801

      cs-801
        cs-801 is a highly performance spectrophotometer with test caliber sideward. the instrument adopts the geometric conditions of d/8 lighting and observation of cie recommendations, integration of the full band led composite light source, double beam optical system, etc real-time calibration technology, spectral reflectance standard deviation within 0.08, maximum of colorimetric values δe*ab is 0.03, to provide all the necessary color formula, coating, printing, textile, meet plastic, food, medicine, automobile field measurement needs.
      1.product introduction

      cs-801uses d /8锛坉iffused illumination/8°锛?design the side type test caliber, can measure state of solid, samples of different particles, powder, paste etc. easily.
      solid samples (steel, cloth) can be placed directly on the measurement port, particles (tablets, master batch), powder (pigment, coffee), paste objects (tomato sauce) can be placed in a petri dish, and then placed in the mouth of the measurement test.


      using etc (every test calibration) real-time calibration technique, in each measurement, the spectrophotometer will be to calibrate the system hardware and software. this technique solves the problem of long-term stability and measurement data drift color measuring instrument fundamentally. spectral reflectance standard deviation within 0.08, chroma value delta e*ab maximum value of 0.03, the inter-instrument agreement is less than 0.2.




      illumination d/8(diffused lighting, 8 degrees observe angle锛夛紙conform to cie no.15銆両so 7724/1銆丄stm e1164銆丏in 5033 teil7銆丣is z8722 condition c standards锛?/td>
      size of integrating sphere φ40mm锛孉lvan diffused reflection surface coating
      illumination light source cleds(entire wavelength balanced led light source锛?/td>
      sensor dual light path sensor array
      wavelength range 400-700nm
      wavelength interval 10nm
      half spectral width 5nm
      reflectivity range 0-200%
      reflectivity resolution 0.01%
      observation angle 2°/10°
      measurement light source a,c,d50,d55,d65,d75,f1,f2,f3,f4,f5,f6,f7,f8,f9,f10,
      f11,f12,dlf,tl83,tl84,nbf,u30,cwf
      data being displayed spd distribution/data, sample's color values, color difference values/graph, pass/fail results, color error tendency, color simulation, display measurement area,history data color simulation, manual input standard sample, generate measurement report
      measurement time about 1 second
      measurement time interval 0.5 second
      measuring caliber φ11mm
      color space cie-l*a*b,l*c*h,l*u*v,xyz,yxy,reflectivity,hunterlab,munsell mi,cmyk

      color difference formulas δe*ab,δe*ch,δe*uv,δe*cmc(2:1),δe*cmc(1:1),δe*94,δe*00,δeab(hunter),555,color classification

      other colorimetric indices wi(astm e313-00,astm e313-73,cie/iso,aatcc,hunter,taube berger stensby),yi(astm d1925,astm e313-00,astm e313-73),
      tint(astm e313,cie,ganz),metamerism index milm,
      adhesive/changing color fastness, iso luminance,8 gloss, a density, t density,e density, m density

      repeatability light splitting reflectivity锛歴tandard deviation within 0.08%
      color values锛?delta;e*ab<=0.015锛圓fter calibration, standard deviation of 30 measurements on test white board, 5 second intervals锛夛紝maximum锛?.03
      battery capacity rechargeable, 20000 continuous tests, 7.4v/6000mah
      interface usb
      data storage 40000 test results
      light source longevity 10 years, 3 million tests
      inter-instrument agreement δe*ab within 0.2锛圔cra color charts ii, average of the 12 charts锛?/td>
      size 350*300*200mm(l*w*h)
      weight about 4.5kg
      display 5-inch true color screen
      work temperature range 0~45鈩? relative humidity 80% or below锛坅t 35°c锛夛紝no condensation
      storage temperature range -25鈩僼o 55鈩冿紝relative humidity 80% or below锛坅t 35°c锛夛紝no condensation
      standard accessories ac power line, manual, color management software, drive software, electronic manual, color management guide, usb cable, black/white calibration tube, electronic color charts
      optional accessories powder molding device,  measurement and test report
      color matching system matches
      uv light source does not include uv light source
      product characteristic
      1. test caliber upward, can measure state of solid, samples of different particles, powder, paste etc. easily
      2.       φ11mm measuring caliber
      3. l  uses led light source; high capacity rechargeable lithium-ion battery 3000000 times in 10 years
      4. l  can measure both sci(specular included)and sce(specular excluded) at the same time
      5. l  obtained china metrology accreditation certificate
      6. l  5-inch tft color screen
      7. l  usb data transmission, includes pc software to manage data
      8. l  large data storage锛欳an record 40000 test data
      9. l  modern and fashionable design based on human engineering
      10. l  easy to use operation modes and compact operation interface
      11. l  design of low power consumption, large capacity rechargeable lithium battery configuration
      12. l  can connect to mini-printers for printing

      application cases

      1. measurement for the cloth color


      2. measurement for liquid color


      1.       three years quality assurance;
      2.       if there are quality problems with the instrument, we offer replacement instrument for the user;
      3.       every instrument comes with metrology test report to ensure the authority of measurement data.
