illumination |
d/8(diffused lighting, 8 degrees observe angle) scs optical engine(light splitting and integration system),etc (real time calibration technology), sci(specular reflection included) /sce(specular reflection excluded)simultaneous measurement銆?conform to cie no.15銆両so 7724/1銆丄stm e1164銆丏in 5033 teil7銆?nbsp;jis z8722 condition c standards) |
size of integrating sphere | φ40mm锛孉lvan diffused reflection surface coating |
illumination light source | composite leds(entire wavelength balanced led light source) |
sensor | dual light path sensor array |
wavelength range | 400-700nm |
wavelength interval | 10nm |
half spectral width | 5nm |
reflectivity range | 0-200% |
reflectivity resolution | 0.01% |
observation angle | 2°/10° |
measurement light source |
a,c,d50,d55,d65,d75,f1,f2,f3,f4,f5,f6,f7,f8,f9,f10,f11,f12, cwf,u30,dlf,nbf,tl83,tl84 |
data being displayed |
spd distribution/data锛宻ample's color values锛宑olor difference values/graph锛宲ass/fail results锛宑olor error tendency锛宑olor simulation锛宒isplay measurement area锛宧istory data color simulation锛宮anual input standard sample锛実enerate measurement report |
measurement time interval | 0.5 seconds |
measurement time | 1 second |
color space | cie-l*a*b,l*c*h,l*u*v,xyz,yxy,reflectivity,hunterlab,munsell mi |
color difference formulas |
δe*ab,δe*ch,δe*uv,δe*cmc(2:1),δe*cmc(1:1),δe*94,δe*00,δeab(hunter),555 ,color classification |
other colorimetric indices |
wi(astm e313-00,astm e313-73,cie/iso,aatcc,hunter,taube berger stensby),yi(astm d1925,astm e313-00,astm e313-73),tint(astm e313,cie,ganz),metamerism index milm, adhesive/changing color fastness, iso luminance,8 gloss, a density, t density |
repeatability |
light splitting reflectivity锛歴tandard deviation within 0.08% color values锛?delta;e*ab<=0.015锛圓fter calibration, standard deviation of 30 measurements on test white board, 5 second intervals锛夛紝 maximum锛?.03 |
battery capacity | rechargeable, 20000 continuous tests, 7.4v/6000mah |
interface | usb, bluetooth |
data storage | 40000 test results |
light source longevity | 10 years, 3 million tests |
inter-instrument agreement | δe*ab within 0.2(bcra color charts ii, average of the 12 charts) |
size | 181*73*112mm(l*w*h) |
weight | about 550g(does not include battery's weight) |
display | true color screen that includes all colors |
work temperature range | 0~45鈩? relative humidity 80% or below( at 35°c ),no condensation |
storage temperature range | -25鈩?nbsp;to 55鈩冿紝relative humidity 80% or below(at 35°c ),no condensation |
standard accessories |
dc adapter, lithium battery, manual, color management software, drive software, electronic manual, color management guide, usb cable, black/white calibration tube, protective cover, spire lamella, portable bag, electronic color charts |
optional accessories | powder molding device, microprinter, measurement and test report |
color matching system | matches |
uv light source | does not include uv light source |
