type | cs-580 |
illumination |
d/8(diffused lighting, 8 degrees observe angle) scs optical engine(light splitting and integration system),etc(real time calibration technology), sci(specular reflection included)/sce(specular reflection excluded) simultaneous measurement銆?br /> (conform to cie no.15銆両so 7724/1銆丄stm e1164銆丏in 5033 teil7銆?nbsp;jis z8722 condition c standards) |
size of integrating sphere | φ40mm锛孉lvan diffused reflection surface coating |
illumination light source | cleds(entire wavelength balanced led light source) |
sensor | blue light enhanced sensor array |
wavelength range | 400-700nm |
wavelength interval | 10nm |
half spectral width | 5nm |
reflectivity range | 0-200% |
reflectivity resolution | 0.01% |
observation angle | 2°/10° |
measurement light source |
a,c,d50,d55,d65,d75,f1,f2,f3,f4,f5,f6,f7,f8,f9,f10,f11,f12,cwf,u30,dlf, nbf,tl83,tl84 |
data being displayed | spd distribution/data锛宻ample's color values锛宑olor difference values/graph锛宲ass/fail results锛?br /> color error tendency锛宑olor simulation锛宒isplay measurement area锛宧istory data color simulation锛宮anual input standard sample锛実enerate measurement report |
measurement time interval | 2 seconds |
measurement time | 1 second |
measuring aperture | φ8mm |
color space | cie-l*a*b, l*c*h, l*u*v, xyz, yxy, reflectance |
color difference formulas | δe*ab, δe*ch, δe*uv, δe*cmc(2:1), δe*cmc(1:1),δe*94,δe*00 |
other colorimetric indices |
wi(astm e313-10,astm e313-73,cie/iso, aatcc, hunter, taube berger, ganz, stensby), yi(astm d1925锛孉stm e313-00,astm e313-73), tint(astm e313,cie,ganz), metamerism index milm, stick color fastness, color fastness |
repeatability |
light splitting reflectivity锛歴tandard deviation within 0.08% color values锛?delta;e*ab<=0.03(after calibration, standard deviation of 30 measurements on test white board, 5 second intervals),maximum锛?.05 |
battery capacity | rechargeable, 10000 continuous tests, 7.4v/6000mah |
interface | usb |
data storage | 20000 test results |
light source longevity | 5 years, 1.5 million tests |
inter-instrument agreement | δe*ab within 0.2(bcra color charts ii, average of the 12 charts) |
size | 181*73*112mm(l*w*h) |
weight | about 550g(does not include battery's weight) |
display | true color screen that includes all colors |
work temperature range | 0~45鈩? relative humidity 80% or below( at 35°c ),no condensation |
storage temperature range | -25鈩?nbsp;to 55鈩冿紝relative humidity 80% or below(at 35°c ),no condensation |
standard accessories |
dc adapter, lithium battery, manual, color management software, d rive software, electronic manual, color management guide, usb cable, black/white calibration tube,protective cover, spire lamella, portable bag, electronic color charts |
optional accessories | powder molding device, micro printer, measurement and test report |
color matching system | not match |
uv light source | does not include uv light source |
